HIDEA Australia Long Open Link Chain: Your Go-To Solution for Secure Mooring and Anchoring

AUSTRALIA STANDARD LONG LINK CHAIN

Material: Carbon Steel Mild Steel
Surface Treatment: Electro OR Hot Dip galvanized, Blackened or as requested
Australia Standard Long Link Chain

Inquire Now

QINGDAO HIDEA PARAMETER SHEET FOR

30SC139 Australia Standard Long Link Chain

Size	Working Load	Inside Length	Outside Width	Links Per m	Length Per 100kg		B.F weight	H.D.G weight
					B.F	H.D.G
mm	mt	mm	mm	pc	m	m	kg/m	kg/m
3	0.05	22.1	15.7	45.3	555	526	0.18	0.19
4	0.09	25.4	18.6	39.3	345	323	0.29	0.31
5	0.19	29.3	21.8	34.1	217	206	0.46	0.49
6	0.32	34.5	26.1	29	135	128	0.74	0.78
8	0.53	41.2	31.9	24.3	82.2	78.1	1.22	1.28
10	0.83	49	38.7	20.4	52.9	50.2	1.89	1.99
