Forged super alloy steel-Quenched and Tempered
Suitable for EN818-2 G80 chain
Individually proof test at 2.5 times Working Load Limit
Fatigue tested at 1.5 times Working Load Limit for 20000 cycles
Breakage test
100% magnaflux crack detection
With cast latch
Surface finish: Powder plastified
Colour code: Red RAL3020/Yellow RAL1003
QINGDAO HIDEA PARAMETER SHEET FOR
20RH433-G80 EUROPEAN TYPE EYE SLIP HOOK-2
| ITEM NO. | WEIGHT (KG) | WLL (T) | B.L (T) | M±2 | A±2 | E±2 | H±3 | B±3 | L±3 | D±3 | ||||
| 20RH433-06 | 0.3 | 1.12 | 4.48 | 20.5 | 9 | 18.5 | 20 | 68 | 109 | 17 | ||||
| 20RH433-7/8 | 0.55 | 2 | 8 | 25 | 11 | 22 | 27 | 84 | 133.5 | 24 | ||||
| 20RH433-10 | 1.05 | 3.15 | 12.6 | 34 | 14 | 28 | 33 | 102.5 | 167.5 | 29 | ||||
| 20RH433-13 | 1.75 | 5.3 | 21.2 | 42.5 | 17.5 | 35 | 40 | 128.5 | 207.5 | 36 | ||||
| 20RH433-16 | 3.2 | 8 | 32 | 52 | 22 | 43 | 48 | 156.5 | 253 | 50 | ||||
| 20RH433-20 | 5.3 | 12.5 | 50 | 62 | 26 | 51.5 | 56 | 187 | 300 | 60 | ||||
