Raw Material 100% high tenacity and tensile strength polyester yarns of low elongation for lifting webbing slings
Colors coded and application properties constructed according to EN1492-1, also meeting ISO4878, machinery directive 2006/42/EC, ASME B30.9, compliant with GS, CE safety requirements
Webbing can also be constructed single, triple and four plies upon request
Safety Factors 5:1, 6:1, 7:1 and 8:1 available upon request; clearly marked with WLL and length on surface of sling and a tag with serial number and technical data
QINGDAO HIDEA PARAMETER SHEET FOR
DOUBLE PLY(DUPLEX)EYE-EYE WEBBING SLING
WL500KG | WORKING LOAD LIMIT IN Kgs WITH ONE WEBBING SLING | ||||||||
| STRAIGHT LIFT | CHOKED LIFT | LIFTING AT AN ANGLEβ | |||||||
| 0°-7° | 7°-45° | 45°-60° | |||||||
| Stock Number | COLOR | W.L.L. (Kgs) | WIDTH (mm) | 1.0 | 0.8 | 2.0 | 1.4 | 1.0 | |
| WS1 | 1,000 | 25/30/50 | 1,000 | 800 | 2,000 | 1,400 | 1000 | ||
| WS2 | 2,000 | 50/60/75 | 2,000 | 1,600 | 4,000 | 2,800 | 2,000 | ||
| WS3 | 3000 | 75/90 | 3,000 | 2,400 | 6,000 | 4,200 | 3,000 | ||
| WS4 | 4,000 | 100/120 | 4,000 | 3,200 | 8,000 | 5,600 | 4,000 | ||
| WS5 | 5,000 | 125/150 | 5,000 | 4,000 | 10,000 | 7,000 | 5000 | ||
| WS6 | 6,000 | 150/180 | 6,000 | 4,800 | 12,000 | 8.400 | 6,000 | ||
| WS8 | 8,000 | 200/240 | 8,000 | 6,400 | 16,000 | 11,200 | 8,000 | ||
| WS10 | 10,000 | 250/300 | 10,000 | 8,000 | 20,000 | 14,000 | 10,000 | ||
| WS12 | 12,000 | 300 | 12,000 | 9,600 | 24,000 | 16,800 | 12,000 | ||
