Hidea Marine-Grade Stainless Steel U-Bolt for Secure and Corrosion-Resistant Fastening

U BOLT

Technical Data: Investment Casting/Forged
Material: AISI 304/INOX A2, AISI 316/INOX A4
Surface Treatment: Electro Polished/Passivated

Inquire Now

QINGDAO HIDEA PARAMETER SHEET FOR

U Bolt

D(mm)	L(mm)	L1(mm)	A(mm)	WT(kgs)
M4	64	30	30	0.021
M5	80	40	35	0.033
M6	80	40	35	0.046
M6	90	40	35	0.049
M8	60	25	35	0.034
M8	80	40	35	0.077
M8	90	50	35	0.0835
M8	100	50	35	0.088
M10	90	40	50	0.098
M10	130	55	50	0.196
M12	150	65	60	0.295
