HIDEA Hatch Board Anchor Chain – Secure and Reliable Marine Solution

HATCH BOARD CHAIN

Material: High-Quality Alloy Steel
Surface Treatment: Blackened, Powder Coated, Hot-dip OR Electro-galvanized etc.
Hatch Board Chain, Hatch Cover Chain

Inquire Now

QINGDAO HIDEA PARAMETER SHEET FOR

30SC116 Hatch Board Chain

Diameter D	Inside Length L	Inside Width B	Proof Load	Breaking Load	Weight
mm	mm	mm	kn	kn	kg/m
11	43	12.5	57	116	2.39
14(A)	50	17	97	194	3.95
14(B)	42	18	97	194	4.32
15	42	21	106	212	5.2
16(A)	55	22	128	254	5.34
16(B)	55	18	128	254	5.29
18(A)	54	24	161	322	7.12
18(B)	64	25	161	322	6.32
19	57	24	164	330	7.6
20(A)	60	22	129	359	9.5
20(B)	62	22	179	359	8.57
22(A)	78	31	240	480	9.86
22(B)	86	30	240	480	9.24
22(C)	66	31	240	480	10.6
30	108	35	399	798	18.22
