HIDEA Short Link Chain: Premium Korean Standard Link Chain for Various Applications

KOREAN STANDARD SHORT LINK CHAIN

Material: Carbon Steel Mild Steel
Surface Treatment: Electro OR Hot Dip galvanized, Blackened or as requested
Korean Standard Short Link Chain

Inquire Now

QINGDAO HIDEA PARAMETER SHEET FOR

30SC141 Korean Standard Short Link Chain

Size	Material Dia.	Inside Length	Inside Width	Length Per Pc	Weight Per Pc
mm	mm	mm	mm	m	kg
3	3	23	5	30	4.50
4	4	22	8	30	9.00
5	5	24	8	30	12.74
6	6	27	10	30	18.86
7	7	31	12	15	14.14
8	8	35	14	15	17.23
9	9	39	15	15	22.13
12	12	38	18	15	45.00
15	15	45	23	15	75.45
16	16	53	23	15	76.41
19	19	58	25	10	78.28
