HIDEA Stainless Steel Eye & Eye Turnbuckle – Ideal for Rigging, Lifting, and Tensioning

KOREAN TYPE TURNBUCKLE (HOOK AND EYE)

Technical Data: Investment Casting/Forged
Material: AISI 304/INOX A2, AISI 316/INOX A4
Surface Treatment: Electro Polished/Passivated

Inquire Now

QINGDAO HIDEA PARAMETER SHEET FOR

Korean type turnbuckle(hook and eye)

Size	A	D	G	H	L	LO
1/4	5.40	11.00	43.00	90.00	124.00	185.00
5/16	6.90	14.00	53.00	110.00	154.00	230.00
3/8	8.30	17.00	77.50	160.00	213.00	333.00
1/2	11.10	20.00	85.00	175.00	239.00	409.00
5/8	14.20	25.00	107.00	220.00	301.00	465.00
3/4	17.20	35.00	119.00	242.00	347.00	523.00
