TIRE SIZE TABLE FOR KN / KNS/ KL & KP SNOW CHAINS

  • Tire size table for KN / KNS / KL & KP series snow chains

  • The tire table is more suitable for European users

  • All snow chains can be customized with supplied layout, drawings or samples

  • Please make sure the snow chains match the tire size before purchase / installation

  • Meeting and complying with NORMS of US NACM - 92805 (TC), NORMS OF European EN 16662-1, ÖNORM and TÜV


HIDEA Tire Size Table for KN / KNS / KL / KP Series Snow Chains

QINGDAO HIDEA PARAMETER SHEET FOR

TIRE  SIZE  TABLE  FOR  KN/KNS/KL  &KP  SNOW  CHAINS

ITEM   NOTIRE SIZE
010   145-10;125-12;150/65-315;145/70-12
020   135-12;135-13;140-12;145-12;150-12;135/70-13;145/70-13;150/65-340;155/65-13;155/70-12;160/60-315
030   125-15;135-14;145-13;155-12;560-12;600-12;155/70-13;160/65-340;165/60-13;165/70-12;175/60-13
040   135-15;145-14;155-13;165/60-14;165/65-14;165/70-13;170/65-340;175/60-14;175/65-13;180/60-340;
  180/65-315;185/60-13;190/55-340;195/55-13
045   175/60-14:155/65-15:185/55-14
050   145-15;155-14;165-13;170-13:520-14:560-13:560-14:590-13;165/70-14:170/65-365;175/65-14;175/70-13;
  180/65-340:185/60-14:185/65-13:190/55-365
060   155-15;165-14;175-13;560-15;600-15;640-13;165/75-14;175/70-14;180/65-365;185/55-15;185/65-14;
  185/70-13;195/50-15;195/60-14;195/60-365;195/65-13;205/60-13:200/65-340
065   185/70-14;185/60-15;215/40-16;205/55-14;195/55-15:205/50-15
070   165-15;175-14;185-13;175/70-15;175/75-14;180/65-390;185/60-15;185/65-15;185/70-14;195/55-15;195/60-15;
  195/65-14;195/70-13;200/55-390:200/60-365:205/50-15:205/55-15:205/60-14:210/55-365;185-14;205/45-16
080   175-15;185-14;185/70-15;190/65-390;195/65-15;195/70-14;200/60-390;205/60-15;205/65-14;
  205/70-13:210/55-390:210/65-365:220/50-365:225/55-14:215/45-17:205/50-16
090   180-15;185-15;195-14;205-14;195/70-15;235/45-17;205/65-15;205/70-14;205/55-16;
  215/60-15:220/55-390:225/50-16
095   235/60-14;195/75-15;205/65-16;215/50-17;205/70-15;215/55-16;225/45-17;215/65-15;245/40-17;225/60-15;
  235/55-15;225/50-16
100   195-15:235/60-15;215/70-14;205/70-15:215/70-15:240/55-390;225/60-15:FR78-15;215/60-16:
  205/65-16:215/55-16
110   225/60-16;215/60-16;225/65-15;225/55-16;235/55-16;225/50-17;235/40-18;215/55-17
120   225/70-15:225/55-17:235/60-16:235/50-18:245/45-18:245/45-17
130   245/60-15:245/55-16:255/50-16:235/55-17:245/50-17:275/40-17:225/65-17
140   225/75-16;245/70-16;245/75-16;265-15;265/70-15:275/60-15
